Програмна карта за YEP контролери

355000020

20,83 лв.
YEP ESC Programming Card
Количество
на склад

Програмна карта за YEP контролери

This is the programming card for the YEP ESCs. This card allows you access to all of the programing options. Its compact size allows it to be stored in your field box or pocket with ease.

Programming Options:
• Active free-wheeling circuit mode: Freew. off/Freew. on
• Govenor mode: Gov. off/Gov. store/Gov./fast Gov.
• Govenor mode P-gain: 0.7/0.9/1.2/1.4/1.6/1.9
• Govenor mode I-gain: 0.02/0.03/0.05/0.06/0.08/0.09
• Startup speed: Heli slow/Heli middle/Heli fast/Plane slow/Plane middle/Plane fast
• PWM frequency: 8kHz/9kHz/10kHz/12kHz/14kHz/16kHz
• Start-up power: Auto 1~32%/2%/4%/8%/16%/32%
• Motor timing: 0°/6°/12°/18°/24°/30°
• Brake: off/Acro/Acro hard/smooth/middle/hard
• Cut-off type: off/slow down/cut-off/NiMh/LiFe/LiPo
• Cut-off voltage (LiFe mode): 2.2/2.3/2.4/2.5/2.6/2.7
• Cut-off voltage (LiPo mode): 2.9/3.0/3.1/3.2/3.3/3.4
• Cells: 4/5/6/7/8/9
• Cells: 10/11/12/13/14/15
• Special functions: Beep short/Rev./Stop/Full speed/F3A brake/Auto timing

 This programming card is suitable for YEP and RotorStar ESCs.
